MIXED-SIGNAL ASICs
for Aerospace & Defense

SimpleChips is offering ASICs design and manufacturing services for demanding Aerospace and Defense applications. We specialize in integrating analog high voltage components with digital functionality to provide compact and reliable designs.

Applications

System-to-ASIC integration
Legacy remake
FPGA-to-ASIC conversion

Features

High voltage analog capability
Rad-hard processes/designs
Low NRE approach
Low/medium volume manufacturing
US based manufacturing
ITAR Registered (M42636)

Services

System-to-ASIC integration
Legacy remake
FPGA-to-ASIC conversion

related products

14SCT000

12V Photo-voltaic diode stack

Resistor programmable current limiters for use in opto-coupler or solid-state relays were a premium is placed on product quality and performance

15SCT000

2-channel Rad-Hard Residual Current Device

Dual-channel control circuit intended for application in a Residual Current Circuit Breaker (RCBO) or Residual Current Device (RCD).

10SCT

Transient surge suppressors

These low cost SCR-based TVS are ultra fast with a typical clamping speed of 20nSec.

16SCT001

1200V Direct-Coupled FET IGBT Gate Driver

For systems requiring the ability to control the conduction state of a high-voltage MOSFET / IGBT switch

18SCT005

1200V Voltage Monitor

The 18SCT005 is a very accurate (+/-0.4%) voltage divider typically used to sense system voltage from +/-150V to +/-1200V.

17SCT002

Direct-coupled high-voltage (1kV) current limiter

The 17SCT004A can very efficiently discharge high-voltage capacitors when needed while protecting itself and surrounding circuitry.

16SCT000

Transformer-Coupled FET/IGBT Gate Driver

Control of the conduction state of a high-side switch from the secondary of a small high voltage isolation transformer.

CL2

Temperature Compensated Unipolar Current Regulator with Enable pin

Temperature-compensated unipolar current regulator with enable pin. Versions available from 5mA to 30mA

14SCT001, 14SCT002

Opto-coupler or SSR LED driver

Resistor programmable current limiters for use in opto-coupler or solid-state relays were a premium is placed on product quality and performance

16SCT100

1200V High Side Switch

1200V 15A fully integrated half-bridge high-side switch typically used in systems requiring H-bridges

17SCT004A

1200V Current limiter with enable and temperature protection

The 17SCT004A can very efficiently discharge high-voltage capacitors when needed while protecting itself and surrounding circuitry.

CL1

Temperature Compensated Unipolar Current Regulators

Temperature-compensated unipolar current regulator. Versions available from 5mA to 30mA

Reach out, and Lets explore how SimpleChips can solve your IC challenges
